LCL filter reactor is a common power supply filter reactor, mainly used in DC power supply three-phase converter filtering at the output. It realizes the filtering of high-frequency noise by using inductors and capacitors to ensure the stability and quality of the output signal. The LCL filter reactor consists of three parts: the input inductor, the series capacitor, and the output inductor. The input and output inductors are coils, while the series capacitor is a fixed-value capacitor. These three components are connected in a specific manner to form a loop structure.
The working principle of the LCL filter reactor reactor can be divided into two stages: the power and load stages.
Power Stage:
In the power stage, the DC power passes through a three-phase converter and then enters the LCL filter reactor. Here, the LCL filter reactor filter reactors the DC signal and converts it into a stable DC signal.
Load Stage:
In the load stage, the stable DC signal enters the load. At this point, the LCL filter reactor continues to filter reactor any residual high-frequency noise, ensuring that the output signal is clean, stable, and reliable.
| Inductance | L1 0.52 mH +/- 10% L2 0.612 mH +/- 10% L3 0.942 mH +/- 10% |
| Rated Voltage | 480V |
| Rated Current | 208A |
| Capacitor | 105μF ± 3% 9.12kVar 480V.ac 60Hz |
| Phase | Three |
| Frequency | 50/60Hz |
| conductor material | Copper |
| temperature rise | ≤ 60K |
| Noise | <70dB@1m |
| Isolation Class | H class |
| Cooling month | AN |
